751320 - Microcompact analog/analog converter

751320 - Microcompact analog/analog converter

Part No.
751320
Type
LCON AA DFDT 806211
Article on stock
PU
1 piece
Interface Technology
Microcompact analog/analog converter

Description

Input: ±30 V, ±50 mA, ±DC 5 A adjustable
Output: 0–20 mA / 4–20 mA / 0–10 V / -10–10 V / 2–10 V / 0–5 V / 1–5 V
Insulation: 2.5 kV, 3-way isolation

Technical Data

Input

Input variable
Analogue signals
Measurement input
  • +30/-30 V, +50/-50 mA, DC +5 A/-5 A
  • adjustable via switch and software FDT/DTM, connection via micro USB
Galvanic isolation I/O
3-way isolation
Step response (10–90%)
1.5 ms–750 ms (adjustable by means of filter stage 1–5, default: filter stage 4 = 200 ms)
Parameterisation
  • Software FDT/DTM
  • DIP switch
Zero /Span
freely adjustable
Input resistance
>800 k @ +30/-30 V, <30 @ +50/-50 mA, 10 m @ DC +5 A/-5 A

Output

Output signal
0–10 V, -10–10 V, 0–20 mA, 4–20 mA adjustable via switch and software FDT/DTM, connection via USB service cable
Max. load impedance at I-output
700 @ 0–20 mA, 4–20 mA
Min. load impedance at U-output
2 k @ 0–10 V, -10–+10 V
Limitation for exceeding measurement range
  • 10.25 V @ 0–10 V, -10–10 V
  • 20.5 mA @ 0–20 mA, 4–20 mA
max. modulation range/output signal/output current
  • 10.5 V @ 0–10 V, -10–10 V
  • 21 mA @ 0–20 mA, 4–20 mA
Parameterisation
  • Software FDT/DTM
  • DIP switch

Operating data

Accuracy
  • 0.1 % FSR @ +30/-30 V, +50/-50 mA
  • 0.5 % FSR @ +5 A/-5 A
Linearity error
  • ±0.05 % FSR @ +30/-30 V, +50/-50 mA
  • ±0,1 % FSR @ +5 A/-5 A

General

Rated voltage UN
DC 24 V
Operation voltage range
16.8–30 V
Rated current
approx. 18 mA
Status indication
LED green, red (error)
Input/output protection
Overvoltage DC 30 V, short circuit-proof output
Temperature error
<100 ppm/K FSR
Data storage
Flash
Insulation voltage input / output
2.5 kVeff
Resolution
16-bit
Configuration
Switch and software: FDT / DTM
Housing material
PA 6.6 (UL 94 V-0)
Color of the housing
light grey
Mounting
  • DIN rail mountable TS35
  • (EN 60715)
Protection class
IP20
Installation position
any
Connection type
  • Spring terminal
  • 0.14 mm2 – 1.5 mm2
Operation temperature range
-40 °C … +70 °C
Storage temperature range
-40°C…85°C
Dimensions (w × h × d)
6,2×90×115,5 mm
Weight
0,05 kg/piece
PU
1 piece
Certifications
  • cULus (E135145)
  • Cl.1 Div2, Gr. A, B, C, D, T4A
  • GL
Standards
EN 60947-5-1

Failure Rate Prediction (MTBF)

Standards
  • Electronic components – Reliability – Reference conditions for failure rates and stress models for conversion: EN/IEC 61709
  • Failure Rates of Components – Expected values: SN 29500
Failure rate at +45 °C
607 fit
Failure rate at +45 °C
1647753 h
1 fit equals one failure per 109 component hours
The indicated temperature is the mean component ambient temperature.
Comments
  • The results are valid under following conditions:
  • Automotive environment or industrial areas without extreme dust levels and harmful substances
Comments
NOTE: The device can be configured using the DIP switches on the side or using the accessory LCON ZB service cable (Item no. 750894).
