762185 - DC/DC converter

762185 - DC/DC converter

Part No.
762185
Type
CV 7-2185 DC24V/24V
PU
1 piece
Power supply
DC/DC converter

Description

DC/DC converter, 1-channel
Input: DC 24 V
Output: DC 24 V

Technical Data

Input

Rated voltage UN
DC 24 V
Operation voltage range
DC 16.8–30 V
Rated current IN
21.5 mA

Output

Rated voltage UN
DC 24 V
Rated current IN
0,03 A
Short-circuit current
<900 mA
Load regulation
<1 %
Rise time
<20 ms
Ripple and Noise
<20 mVeffeff
Parallel / redundant mode
No
Short circuit
Current limit

General

Insulation voltage input / output
1.5 kVeff
Rated insulation voltage (EN 50178)
50 V
Operation temperature range
-25 °C … +60 °C
Storage temperature range
-40°C…85°C
Cooling
Air convection
Housing material
PA
Mounting
  • DIN rail mountable TS35
  • (EN 60715)
Installation position
any
Protection class
IP20 (IEC 529 / EN 60529)
Over voltage category
I
Degree of polution
2
Weight
0,04 kg/piece
Connection type
  • Screw terminal
  • 0.14 mm2 – 1.5 mm2
Dimensions (w × h × d)
6,2×90×92,5 mm
PU
1 piece
Dimensions
PIN assignment
Accessories
  • Jumper comb 6 A, red: 2-pin: Part-No. 762802 | 3-pin: Part-No. 762805 | 4-pin: Part-No. 762812 | 8-pin: Part-No. 762822 | 16-pin: Part-No. 762832 | PU: 10 units
  • Jumper comb 6 A, white: 2-pin: Part-No. 762803 | 3-pin: Part-No. 762806 | 4-pin: Part-No. 762813 | 8-pin: Part-No. 762823 | 16-pin: Part-No. 762833 | PU: 10 units
  • Jumper comb 6 A, blue: 2-pin: Part-No. 762804 | 3-pin: Part-No. 762807 | 4-pin: Part-No. 762814 | 8-pin: Part-No. 762824 | 16-pin: Part-No. 762834 | PU: 10 units
  • Labelling sign 4×11 mm, white: Part-No. 681313 | BZT-0411 | PU: 100 units
  • Insulation plate, black RAL 9005: Part-No. 760809 | TP 7-0809 MIC/SNR | PU: 10 units
  • Laser label A4 not punched, black RAL 9005: Part-No. 681031 | LEB A4 PW | PU: 10 units
